Delphi Axiom Lever Chrome Dual Concealed Shower Set with Fixed Head and Handset

Delphi Axiom Lever Chrome Dual Concealed Shower Set with Fixed Head and Handset

A rainfall head for washing and a handset for everything else, run from one chrome valve: this Axiom Lever set is what most bathrooms actually need. The pin lever and four spoke crosshead sit on a rounded corner rectangular plate, and the 200mm head keeps a flat, thin edged face on its 335mm arm.

Two controls run the shower, one for temperature and one that opens the flow and switches between the outlets. Valve, head, arm and handset set are supplied together for one price.

Bundle Contents

• 1 x Delphi Axiom Lever Chrome 2-Outlet Dual Concealed Shower Valve
• 1 x Delphi Round Chrome Fixed Shower Head 200mm x 200mm
• 1 x Delphi Round Chrome Shower Arm 335mm
• 1 x Delphi Round Pencil Chrome Shower Handset (inc Bracket, Hose and Wall Outlet Elbow)

Shower Valve Features

• Two-handle shower valve, including the concealing plate and valve body in one package
• Two outlets with an integrated diverter, feeding the fixed head or the handset
• Two controls: one sets the temperature, the other turns the shower on and switches between outlets
• Thermostatic cartridge holds your set temperature to within 2 to 3 degrees C
• TMV2 approved, so the flow shuts off if the cold supply fails
• WRAS approved for connection to the mains water supply
• Quarter turn ceramic disc cartridge, highly resistant to limescale
• 215mm x 120mm plate, fitted portrait or landscape, needing a recess 72mm to 85mm deep
• 15mm inlets, working from a minimum of 0.5 bar
• Chrome finish, matched across every piece in the bundle

Fixed Shower Head and Arm Features

• 200mm diameter round spray face, flat and thin edged for a pared back look overhead
• Stainless steel, which will not rust or tarnish in a shower enclosure
• Rub clean silicone nozzles laid out in concentric rows
• Single function rainfall spray, just 55mm deep from face to connector
• Matching round arm projecting 335mm from the finished wall on a 60mm round flange
• 1/2 inch BSP swivel connector, so the spray angle can be adjusted

Handset and Bracket Features

• Single function round pencil handset with a slim cylindrical body
• Round wall bracket fixed at one height, with the water outlet built into it
• Handset lifts out for rinsing and parks back in place, with no height adjustment
• 1500mm flexible shower hose with 1/2 inch BSP connections
• Wall outlet elbow included, connecting the handset straight to the concealed valve
• 5 year guarantee across the bundle against faulty workmanship and materials, with 12 months on serviceable and moving parts

Important Information

• This is a two-outlet shower valve designed for two accessories only (both are included).
