The Sagittarius Ergo Exposed Thermostatic Shower Valve is part of the stylish Sagittarius Ergo Shower Valve Range, made to meet TMV2 standards and finished in mirror polished chrome, this shower would help bring your shower to life. Designed to bring comfort, ease and elegance to your bathroom, the sagittarius ergo thermostatic shower valve has been crafted specifically to ensure safe showering sessions, bereft of the danger of being scalded. This exposed shower valve superior quality material is thermostatically controlled to offer you safe, peaceful and suitable for use with combi-boilers. Products from sagittarius are manufactured to the highest standards, which include BS5412, BS1010, TMV2 & TMV3.
Sagittarius Ergo EL/191/C Shower Valve Features:
- Manufactured from solid brass material for longevity
- Thermostatic control for safety and peace of mind
- Temperature Pre-set maximum at 62.7 degree celsius
- Automatic shut off in the event of hot or cold water supply
- 15mm Compression connection
- Exposed wall mounted installation and Contemporary design
- Valve has adj centres 130mm-160mm so you can replace valve easily without having to worry about re-tilling
- Suitable for high and low pressure systems
- Suitable with combi boilers
- Manufactured to comply with WRAS,TMV2 and BSEN 1111
- Chrome plated to BS EN248
- Supplied with 10 year guarantee from manufacturer (Serviceable parts carry a 3 year guarantee and accessories carry a 1 year Guarantee)
Sagittarius Ergo EL/191/C Shower Valve Specifications:
| Shower Type |
Thermostatic |
|---|
| Shower Valve Controls |
2 |
|---|
| Shower Valve Position |
Exposed |
|---|
| Valve Shape |
Round |
|---|
| Shower Valve Height |
98mm |
| Shower Valve Width |
256mm |
| Shower Valve Depth |
133mm |
| Handle Type |
Lever |
|---|
| Shower Valve Outlets |
1 |
|---|
| Minimum Pressure |
0.5 Bar |
|---|
| Maximum Pressure |
6.0 Bar |
|---|
| Inlet Connection Size |
1/2 BSP |
|---|
| Outlet Connection Size |
1/2 BSP |
|---|
| Connection Centres |
130-160mm |
|---|
| Material |
Brass |
|---|
| Colour |
Chrome |
|---|
| Brand |
Sagittarius |
|---|
| Collection |
Ergo |
|---|
| Style |
Modern |
|---|
| Market |
Domestic |
|---|
| Flow Rate - 0.5 Bar |
5.7 l/min |
|---|
| Flow Rate - 1.0 Bar |
12.4 l/min |
|---|
| Flow Rate - 2.0 Bar |
19.6 l/min |
|---|
| Flow Rate - 3.0 Bar |
25.0 l/min |
|---|
| Flow Rate - 4.0 Bar |
29.6 l/min |
|---|
| Flow Rate - 5.0 Bar |
33.0 l/min |
|---|
| Manufacturer Part Number |
EL/191/C |
