Geberit Duofix 1120mm Wall Hung WC Frame with Delta Cistern and Delta30 Flush Plate

The Geberit Duofix Wall Hung WC Toilet Frame with Delta Concealed Cistern is a pre-plumbed WC frame that provides the flexibility to install the WC in small or awkwardly shaped bathrooms. Depending on the construction situation, the flush plate can be attached to the top or front of the cistern, with no special tools required to install the cistern or the flush plate. This ensures that fitting time and disruption are kept to an absolute minimum on all projects.

Product Features

• Complete with Delta30 gloss chrome flush plate
• Concealed cistern with front actuation
• Frame top open
• Galvanized feet
• Feet adjustable 0-20 cm
• Foot plates made of plastic
• Self-supporting frame, powder-coated
• For drywall construction
• For installation in part or room-height prewall installations
• For wall-hung WCs with connection dimensions in accordance with EN 33:2011For wall-hung WCs with projection up to 62 cm
• Concealed cistern fully insulated against condensation
• Connection bend can be mounted without tools
• Foot plate depth suitable for installation in U-profiles UW 50
• Immediate post flush possible with factory setting
• Water supply connection on the rear or top centre
• Frame with holes to receive Geberit Duofix wall anchors for elements with frame top open
• Frame with 9 mm drilling holes for fastening in wood frame construction
• Frame prepared for support brackets for WC ceramic appliances with small contact surfaces
• Cistern fulfils standard requirements in accordance with EN 14055, Class II
• Equipped with conduit pipe for feed pipe for connection of Geberit AquaClean shower toilets
• With fastening option for electrical connection
• Supplied with a 10 year guarantee on cistern and 5 year on the flush plate from the manufacturer
