The Saniflo Sanicubic 2 Classic Heavy Duty Macerator Pump is a model from one of the most powerful pumps in the Saniflo Professional Range Sanicubic by the Saniflo. The Sanicubic 2 Classic contains two separate, load balanced pumps with high performance macerating systems and will operate alternatively. In the event of inflow overload, both motors run at the same time, or in the unlikely event that one motor fails, the other one will take over.
Saniflo Sanicubic 2 Classic 6103 Macerator Pump Features:
Ideal for busy business environments and larger domestic situations
New design with easily removable motor for servicing and maintenance
Water level indicator unit is now easily removable for service and maintenance
Tough, reliable macerator pump
Load balanced twin macerator pumps for failsafe system
Alternate activation ensures even wear of motors
Two alarms for ultimate safety - both hard-wired
Pumps up to 11m vertically and 110m horizontally
Discharges through 50mm pipework
Centre heights of inlet 140mm
Working temperature of 35 degree C
IP68 rated
Can be connected to a Building Management System
Comes complete with 5 year guarantee from manufacturer for total peace of mind
Saniflo Sanicubic 2 Classic 6103 Macerator Pump Video:
VIDEO
Saniflo Sanicubic 2 Classic 6103 Macerator Pump Specifications:
Height
597mm
Width
426mm
Projection
299mm
Horizontal Discharge
110m
Vertical Discharge
11mm
Maximum Temperature
70 degree C
Discharge Pipe Diameter
50mm
Max. Amperage (A)
40/50/100/110 A
Wattage
2 x 1500w
Electrical Supply (V/Hz)
220-240 / 50 (V/Hz)
Horsepower
45
Maximum current input
13 Amp
Weight
35.50 Kg
EAN Barcode
5055804500626
Manufacturer Part Number
6103
