Smiths Space Saver SS80 Fan Convector - Kitchen Plinth Heater for 8cm Plinths with Stainless Steel Grille is a highly-efficient fan convector that fits into the plinth of a kitchen unit. The Space Saver plinth heater offers increased flexibility and space in kitchen design as it enables the removal of kitchen radiators that may be using up valuable wall space. Fitting discreetly into the plinth of a kitchen, the Space Saver provides efficient and effective heat at low level, creating space for extra cupboards, more work surface and additional appliances.
HOW DOES HYDRONIC FAN CONVECTION WORK?
Fan convectors require connection to a wet central heating system and an electrical connection to run the fan. Hot water passes through the heat exchanger and heat is transfered to the aluminium fins. Cooler air is drawn in and heated before being expelled back into the room. This technology uses, on average, less than 2p of electricity per day. It means that a more even temperature gets distributed and the room will be heated much faster than a traditional panel radiator.
Smiths Space Saver SS80 Plinth Heater Features:
Image is for illustration purpose only Please choose your grill according to model number of your unit Space Saver is designed for use on standard two pipe pumped central heating systems
Pipes are 15mm and either may be used as flow or return
This product is not suitable for one-pipe system
Heat Output: 3000 Btu/h, 900 Watts
Supplied complete with stainless steel fascia grille and pre-wired cable and flexible installation hoses
Creates space for more kitchen cupboards, extra work surface and additional appliances
Connects to and runs from your central heating system
Installs into slim-line 8cm plinths (IKEA)
Room size guide - 27 m
Adds less than 5 pound to your annual heating bills
Choice of three Fascia Grilles colours (See the you may need)
5 Year Parts and Labour Warranty
Smiths Space Saver Plinth Heater Video:
VIDEO
Smiths Space Saver Plinth Heater Installation Guide Video:
VIDEO
Smiths Space Saver SS80 Plinth Heater Specifications:
Fan Convectors Type
Plinth Heater
Fan Convector Height
74mm
Fan Convector Width
550mm
Fuel
Central Heating
Normal Heat Output at 50 degree C (kW)
0.5
Normal Heat Output at 50 degree C (BTU)
1700
Boost Heat Output at 50 degree C (kW)
0.4
Boost Heat Output at 50 degree C (BTU)
1400
Approx Room Size
24
Mounting
Plinth
Material
Stainless Steel
Colour
Stainless Steel
Style
Modern
Market
Domestic
Brand
Smiths
Collection
Space Saver
Manufacturer Part Number
HPSS10009
EAN Barcode
5055804606151
