Delphi Windsor Chrome Dual Concealed Shower Set with Fixed Head and Handset
Compact enough for an en suite but still a two accessory shower, this Windsor set pairs an 8 inch apron rose on a plain round arm with a telephone handset on a fixed wall bracket. We kept both in chrome and matched the white ceramic handle on the handset to the ceramic lever on the stepped valve plate.
The concealed thermostatic valve runs the pair from two controls, one for the temperature and one that switches the water on and diverts between the overhead and the handset. Valve, 200mm head, 335mm arm and handset kit are supplied together for one price.
Bundle Contents
- 1 x Delphi Windsor Chrome 2-Outlet Dual Concealed Shower Valve
- 1 x Delphi Traditional Chrome Fixed Shower Head 200mm x 200mm
- 1 x Delphi Round Chrome Shower Arm 335mm
- 1 x Delphi Traditional Chrome/White Shower Handset (inc Bracket and Hose)
Shower Valve Features
- Two-handle shower valve, including the concealing plate and valve body in one package
- Two outlets fed through an integrated diverter, one for each accessory in the set
- Two controls: one sets the temperature, the other turns the shower on and diverts between outlets
- Thermostatic cartridge holds your set temperature to within 2 degrees C
- TMV2 approved, so the flow shuts off if the cold supply fails
- WRAS approved for connection to the mains water supply
- Quarter turn ceramic disc cartridge, highly resistant to limescale
- 210mm x 120mm stepped plate, mitred at the corners, needing a recess 67mm deep
- 1/2 inch BSP inlets, working from a minimum of 0.5 bar
- Chrome finish, matched across every piece in the bundle
Fixed Shower Head and Arm Features
- 200mm diameter apron rose, an 8 inch traditional head with a domed body and stepped banded rim
- 115mm deep overall, so it reads as brassware rather than a flat disc
- Machined from solid brass with a recessed spray plate hiding the nozzles
- Single function, delivering one soft, wide rainfall spray
- Matching round arm projecting 335mm from the finished wall on a 60mm round flange
- 1/2 inch BSP connections between arm and head
Handset and Bracket Features
- Supplied with the traditional handset, hose, wall bracket and outlet elbow
- Round wall bracket fixed at one height, with the water outlet built into it
- Single function tapered rose with a plain spray face and white ceramic handle
- 1500mm flexible shower hose
- Solid brass construction with 1/2 inch BSP connections
- 5 year guarantee across the bundle against faulty workmanship and materials, with 12 months on serviceable and moving parts
Important Information
- This is a two-outlet shower valve designed for two accessories only (both are included).
