Delphi Windsor Brushed Pewter Dual Concealed Shower Set with Fixed Head and Slide Rail Kit

Delphi Windsor Brushed Pewter Dual Concealed Shower Set with Fixed Head and Slide Rail Kit

A two-outlet Windsor shower set in brushed pewter, covering the 200mm domed rose and its round arm, the 750mm traditional rail with its white handled handset, and the concealed valve that runs them both. The stepped mitred plate carries the same soft grey tone as everything else on the wall.

Two controls do the work, one for temperature and one that opens the flow and diverts between the overhead and the rail. Taking the shine off traditional shapes is the whole idea: period detailing in a bathroom that is meant to feel quiet.

Bundle Contents

• 1 x Delphi Windsor Brushed Pewter 2-Outlet Dual Concealed Shower Valve
• 1 x Delphi Traditional Brushed Pewter Fixed Shower Head 200mm x 200mm
• 1 x Delphi Round Brushed Pewter Shower Arm 335mm
• 1 x Delphi Traditional Brushed Pewter/White Slider Rail Shower Kit (inc Outlet Elbow)

Shower Valve Features

• Two-handle shower valve, including the concealing plate and valve body in one package
• Two outlets fed through an integrated diverter, one for each accessory in the set
• Two controls: one sets the temperature, the other turns the shower on and diverts between outlets
• Thermostatic cartridge holds your set temperature to within 2 degrees C
• TMV2 approved, so the flow shuts off if the cold supply fails
• WRAS approved for connection to the mains water supply
• Quarter turn ceramic disc cartridge, highly resistant to limescale
• 210mm x 120mm stepped plate, mitred at the corners, needing a recess 67mm deep
• 1/2 inch BSP inlets, working from a minimum of 0.5 bar
• Brushed pewter finish, matched across every piece in the bundle

Fixed Shower Head and Arm Features

• 200mm diameter apron rose, an 8 inch traditional head with a domed body and stepped banded rim
• 115mm deep overall, so it reads as brassware rather than a flat disc
• Machined from solid brass with a recessed spray plate hiding the nozzles
• Single function, delivering one soft, wide rainfall spray
• Matching round arm projecting 335mm from the finished wall on a 60mm round flange
• 1/2 inch BSP connections between arm and head

Slide Rail Kit Features

• 750mm rail, 70mm wide, projecting 150mm from the wall
• Lever operated bracket, so the handset locks at any height along the bar
• Single function tapered rose handset with classic white ceramic detailing
• 1500mm flexible shower hose
• Wall outlet elbow included, connecting the kit straight to the concealed valve
• Brass and ABS construction
• 3 year guarantee across the bundle against faulty workmanship and materials, with 12 months on serviceable and moving parts

Important Information

• This is a two-outlet shower valve designed for two accessories only (both are included).
