Geberit Alpha 820mm H Concealed Cistern with Alpha01 Chrome Square Flush Plate

This Geberit Alpha Cistern & Alpha01 Chrome Square Flush Plate with an installation height of 820mm high provides an innovative concealed solution for floor-standing back-to-wall WCs in small spaces opening up opportunities when it comes to the design of your bathroom

Designed to maximise bathroom space its dual top or front flush capability makes it an excellent choice for multiple bathroom layouts, there are no borders anymore to your creativity in bathroom design and the implementation of your ideas

Whether you're upgrading your ensuite, optimising a small space, or installing a back-to-wall WC in a challenging area (under a window, stairs, or roof pitch), this unit delivers flexibility, reliability, and efficiency

Bundle Contents

• 1 x Geberit Alpha Concealed Cistern
• 1 x Geberit Alpha01 Round Flush Plate Chrome
• Geberit Water supply connection unit R 1/2, with integrated angle stop valve and adapter ring
• Geberit Protection box for service opening
• Geberit Fastening for flush bend
• Geberit Flush bend extension, 45mm
• Geberit Protection plug
• 2 x Geberit fixing brackets
• Geberit Fastening materials

Cistern Features

• Space-Saving: Depth of 120mm & installation height of 820mm, making it ideal for compact bathrooms and ensuites
• Dual-Flush System: Offers water-saving options with adjustable flush volumes, helping reduce water consumption
• Leakproof Design: Constructed as a one-piece blow-mold, eliminating unnecessary seals and preventing leaks for maximum reliability
• Compatibility: Works with all Geberit pneumatic flush buttons, providing versatility for various designs
• WRAS approved
• Cistern fully insulated against condensation
• Cistern fulfils standard requirements in accordance with EN 14055, Class II
• Top or Front actuation
• Water supply connection on the rear or left
• Welded flush bend
• Supplied with a 10 year guarantee on cistern and 5 year on the flush plate ( 25 year on spare parts ) from the manufacturer

Flush Plate Features

• Compatibility: Designed to work with all Geberit Alpha concealed cisterns
• Performance: Features a dual flush mechanism for enhanced water efficiency and convenience
• The simplistic yet elegant design of the Geberit Alpha01 Round Flush Plate range offers a subtle finishing touch to your bathroom
• Flush plate dimensions: 142mm H x 213mm W x 16mm D
