Bristan Prism Dual Concealed Mixer Shower with Shower Kit and Fixed Head - Brushed Brass

Product Features

• Pack includes shower valve with integral two outlet diverter, slimline 200mm round drench head with shower arm, and shower kit with an adjustable riser rail plus a multi function handset and wall outlet
• Multi function rub clean handset and drench head - limescale and debris build-up is quickly and easily removed by rubbing a finger or a cloth over the nozzles
• On-trend brushed brass finish to make a statement in your bathroom
• Slim design recessed shower valve will fit into a cavity space as small as 35mm for hassle-free installation
• Dual control - Flow and temperature are operated separately giving accurate control of both
• Cartridge can be accessed from the front for easy servicing
• 15mm inlet connections
• Fitting depth including plasterboard and tiles is 50mm - 75mm
• Body is of brass construction
• Suitable for all plumbing systems
• Guarantee: 5 years including parts (1 year on labour and 3 year on Gold, Painted and other Special Finishes)
• Through Handset (mixed): 0.2 Bar- 2.7 l/min, 0.5 Bar - 5 l/min, 1.0 Bar - 7.3 l/min, 2.0 Bar - 7.8 l/min, 3.0 Bar - 8.9 l/min, 5.0 Bar - 9.8 l/min
• Through Fixed Head (mixed): 0.2 Bar- 3.6 l/min, 0.5 Bar - 5.9 l/min, 1.0 Bar - 6.5 l/min, 2.0 Bar - 8.1 l/min, 3.0 Bar - 8.5 l/min, 5.0 Bar - 9.6 l/min
• Through Handset (without flow regulators): 0.2 Bar- 31 l/min, 0.5 Bar - 5.8 l/min, 1.0 Bar - 8.7 l/min, 2.0 Bar - 12.9 l/min, 3.0 Bar - 16 l/min, 5.0 Bar - 21 l/min
• Through Fixed Head (without flow regulators): 0.2 Bar- 5.9 l/min, 0.5 Bar - 9.3 l/min, 1.0 Bar - 13.5 l/min, 2.0 Bar - 19.5 l/min, 3.0 Bar - 23.3 l/min, 5.0 Bar - 24.8 l/min
