Geberit Duofix 1120mm WC Toilet Frame With 120mm Sigma Cistern for Disabled WC - Blue

This Geberit Sigma wall-hung Frame & Cistern is specifically designed for wall hung pans up to 700mm projection. It also has a reduced width to accommodate support rails or handles next to the frame.

This frame also has the ability during the installation to choose from a WC height ranging from 410mm to 460mm. This makes it the perfect frame for installations in care homes, hospitals, or private residences.

This cistern & frame is equipped for installation requiring electrical connections. This means touchless flush plates, shower toilets, odour extraction units, and other devices can be installed or retro-fitted quickly and easily.

Known for their reliability, every Geberit cistern is leak-tested before it is delivered. The 50-year guaranteed spare parts availability provides long-term security.

Product Features

• Supplied with Sigma 120mm concealed cistern with front actuation
• Engineered with accessibility and strength for disabled-friendly bathrooms in private homes, care homes, hospitals, and commercial settings
• Purpose-built to accommodate wall-hung pans up to 750mm projection
• Reduced frame width allows for support rails or handles, ideal for wheelchair users or those with mobility challenges
• Adjustable WC installation height range between 410-460mm
• Electrical compatibility for advanced hygiene features such as Geberit AquaClean shower toilets and touchless flush plates
• Strong, corrosion-resistant steel frame supports up to 400 kg (63 stone) when used with Geberit wall-hung pans
• Concealed cistern and no exposed pipework for improved hygiene and reduced bacteria build-up
• Integrated acoustic solutions ensure quiet flush operation
• Each cistern is leak-tested before delivery, ensuring reliability
• One-piece blow-moulded cistern provides long-lasting watertight performance
• Easy maintenance access via the flush plate
• Suitable for care homes, hospitals, accessible or disabled bathrooms, and modern residential installations
• Compatible with Geberit Sigma flush plates, Geberit pneumatic flush buttons, Geberit AquaClean shower toilets, and Geberit DuoFresh
• WRAS approved for assured quality and compliance
• Compatible with Geberit Sigma range flush plates (front actuation)
• Factory flush setting of 5.8 / 3 litres, adjustable up to 7.5L large / 4L small flush
• Operates within a water pressure range of 0.1-10 bar
• Maximum operating temperature of 25 degrees Celsius
• Frame made from powder-coated, corrosion-resistant steel
• Sigma 120 mm insulated cistern, EN 14055 Class II certified
• Includes water supply connection 1/2 BSP (female to male), compatible with UK fittings, featuring an integrated isolation (angle) valve and hand wheel
• Protection box for service opening
• WC connection set (90 mm)
• 90 degree connection bend (PE-HD, 90 mm)
• Adaptor socket (PE-HD, 90/110 mm)
• Two protection plugs and two threaded rods (M12)
• Fastening materials included
• Supplied with a 10 year guarantee ( 50 year on spare parts ) from the manufacturer

Important Information

• Flush plate sold separately, (See the You May Need)
