Delphi Axiom Crosshead Chrome 2-Outlet Triple Concealed Shower Valve

Delphi Axiom Crosshead Chrome 2-Outlet Triple Concealed Shower Valve

A three-control Delphi Axiom Crosshead concealed shower valve in chrome, feeding two outlets: the centre handle holds the temperature and the outer two open the overhead and the handset kit independently. Four-spoke crossheads sit on a rounded-corner rectangular plate measuring 280mm by 120mm, modern in outline and classic in detail. Everything but the plate is buried in the wall, and the valve can go in portrait or landscape to suit the space you have.

Product Features

• Three-handle shower valve, including the chrome concealing plate and the valve body
• Two outlets with separate controls, for an overhead and handset kit, alone or together
• Three controls: centre sets the temperature, outer two open one outlet each, alone or together
• Thermostatic cartridge holds your set temperature to within 2 to 3 degrees C
• TMV2 approved, so the flow shuts off if the cold supply fails
• WRAS approved for connection to the mains water supply
• Quarter turn ceramic disc cartridge, precise and limescale resistant in hard water
• Reversible: turn the cartridge 180 degrees instead of re-piping crossed supplies
• 280mm x 120mm plate, needing a recess 72mm to 85mm deep
• 1/2 inch BSP inlets, and the valve fits portrait or landscape
• Works between 0.1 and 3.0 bar
• Delivers 5.5 litres per minute at 0.1 bar, 14 at 0.5 bar, 20 at 1.0 bar
• 5 year guarantee against faulty workmanship and materials, with 12 months on serviceable and moving parts

Important Information

• Supplied as the valve only; the shower head, arm, handset or shower kit it feeds are bought separately
