Looking for a cistern that is not only quick to install but is built to last This Geberit Duofix Omega Cistern is the right choice for you. This frame is pre-plumbed and designed to work with wall-hung WCS.
It features top and front access to the cistern and offers a concealed cistern. It features wall fixing brackets and a 90 degree drainage bend with a conduit pipe. Not only this but it also comes with an extensive Supplied with a 1 year guarantee from the manufacturer, so that you can be sure you are buying quality.
Geberit Duofix 111.061.00.1 WC Frame Features:
For installation in part or full height room installations
With top and front access to cistern
With wall fixing brackets
With 90 degree drainage bend
With conduit pipe for connection to Geberit AquaClean
Maximum operating temperature, water 25°C
Flush volume, factory setting is 5.8 and 3 l
Cistern Fulfils Standard requirements in accordance with EN 14055, Class ll
Concealed cistern with front actuation, fully insulated against condensation
Fastening for connection bend, sound-absorbing
Connection bend can be mounted without tools at different depths, adjustable range 45mm
Foot plates, rotatable, depth suitable for installation in U-profiles UW 50 and UW 75 and Geberit Duofix system rails
Non-slip leg supports
Leg Support zinc plated, adjustable 0-20 cm
Frame prepared for support brackets for WC ceramic appliances with small contract surfaces
Frame with 9 mm drilling holes for fastening in wood frame construction
Self-supporting frame powder-coated
Immediate post flush possible with factory setting
Tool-free installation and maintenance work on concealed cistern
Water supply connection, rear or top centre
Protection cover box for service opening protects against moisture and dirt
Protection box for service opening can be cut to length
Equipped with conduit pipe for feed pipe for connection of Geberit AquaClean shower toilets
Wall fixture variable from 30 - 60 degrees
Flush volume small adjustment range is 3-4 l
Flush plate sold separately, (See the You May Need) Supplied with a 1 year guarantee from the manufacturer
Geberit Duofix 111.061.00.1 WC Frame Video:
VIDEO
Geberit Duofix 111.061.00.1 WC Frame Specifications:
Flush Type
Dual Flush
Flow Pressure
0.1-10 Bar
Width
500mm
Height
1120mm
Cistern Included
Yes
Material
Steel
Finish
Blue
Collection
Duofix
Style
Contemporary
EAN Barcode
4025416320487
Manufacturer Part Number
111.061.00.1
